ABS Concrete Formwork:
Place of Origin:Shandong, China.
Brand Name:GP
Model Number:ABS building formwork panel
Material:ABS+glass fibers+Nylon
Reusable:above 100 times
Construction:panels, corners, handle and accessories
Certificate:ISOTS16949; CNAS Test
Waterproof:Yes
Assemble and disassemble::Easy and quick
Weight:about 15 kg per square meter
Thermal deformation temperature::above 150 degree Celsius
Eco-friendly:Yes
Features of ABS building formwork panel:
1. Long lifespan& Cost effective –The experiment shows that our Plastic Formwork can be reused over 100 times, while the Plywood can only be reused 7 to 10 times. Therefore the Plastic Formwork decreases the cost efficiency
2. Waterproof – For the nature of plastic material, this item is a kind of anticorrosive material, especially suitable for underground and watery circumstances.
3. Easy reassembly– It is easy for worker to operate and split.
4. Pouring expediently-- The template will be separated easily from concrete.
5. Simple Installation – the mass of the product is light, at the same time it is safe to handle and easy to clean.
6. High Quality –it is hard to deformation.
7. Recyclable -- Waste scrap molding board could be recycled.
Products Name: ABS building formwork panel
Original: China
Material:ABS
Maximum Load: 60KN/SQM
Reusable: 100 times
Weight 11KG
Setting up:
1. assemble the formwork as described earlier leaving an opening in the panels where the wood plate has to be mounted. The space remaining will be panelled off by the wood plates (do not use the wood plate along or next to corners, but in a flat area, usually about halfway along the wall)
2. to keep the plates in place and prevent them from falling, fit the spacers and the tie rods in the plates' holes
3. mount the reinforcement bars on the tie rods, one for each stay (i.e. 4 each side for a 3.00m high formwork)
4. lock the reinforcement bar in place by fastening tight the win nuts, making sure the reinforcement bar is kept horizontal. At this stage the wood plates are blocked to the system
Supply Ability:
Supply Ability: 200 Square Meter/Square Meters per Day.
Packaging & Delivery:
Packaging Details: By wooden pallet and covered by pvc film
Port: Qingdao
